Wired In

WEIPU SF12 Connector

WEIPU SF12 Connector

Regular price $14.99 USD
Regular price Sale price $14.99 USD
Sale Sold out
Shipping calculated at checkout.

About WEIPU (from their website):

WEIPU is one of the world’s largest industrial connector manufacturers. Established in 1996, WEIPU specializes in producing the industrial connectors, waterproof connectors, circular connectors and more to ensure safe and reliable power supply solution.


Shell material Brass with chrome plating

Insert material

PPS, max temperature 260 ℃

Contact material

4-pin Brass with gold plating


Solder: SF6B, SF8B, SF10, SF12, SF16, SF20
Crimp: SF16, SF20
Screw: SF20 ( 2.5mm contact)

Cable outer diameter range

SF6B: I:2-3mm, II: 3-4mm
SF8B: I:3-4mm, II:4-5mm
SF10: I:3-4mm, II:4-6.5mm
SF12: I: 4-6.5mm, II: 5-8mm
SF16 I: 5-8mm, II: 8-12mm
SF20 I:5-9mm, II: 8-12mm
IP rating SF6, SF8: IP44 / IP67
SF10, SF12, SF16, SF20: IP67
Temperature rating -40 ~ + 85℃
Insulation resistance 2000 MΩ
Good for Single and double sleeved cables (double recommended)


 Diagram of WEIPU SF12 4 pin connector
View full details

Collapsible content


Custom configure your own mechanical keyboard cable! There are so many options here including making your own color combinations. Please refer to the color guides in the Meterials section.

If you do decide to make your own color, please be descriptive as possible in what you're trying to achieve.

We can combine colors and even add FX such as splatter, fade, and metallic.


The order form may be overwhelming at first but a lot of time was spent making it as clear as possible. Please look through the options carefully and start building!

If you have any additional questions, or need any additional confirmation, reach out to use directly and we can walk you through the process or give you a custom quote.


Shipping usually takes 2-4 weeks (sometimes even sooner!) from the time of purchase. Some custom configurations and made-to-order options may take longer. However, we will always keep you as updated as possible and you can always check in with us to see how your order is doing.
